Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent

  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
  • Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent
Place of Origin CHINA
Brand Name TISCO
Certification ISO,SGS
Model Number NM400,NM450
Minimum Order Quantity 3 tons
Price negotiable
Packaging Details Standard export packing (waterproof paper + steel rings), or as your requirement
Delivery Time ship within 10 days after received the advance
Payment Terms T/T, L/C, Western Union
Supply Ability 3000 tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Nm450 Abrasion Steel Plate Standard AISI, ASTM
Grade NM400,NM450 Thickness 6-200mm
Width 1000-3000mm Length Customized
Technic Hot Rolled Finish 2B/NO.1/BA
Tolerance ±1 Application Boiler Plate, Container Plate
High Light

Ar500 Wear Resistant Steel Plate

,

200mm Wear Resistant Steel Plate

,

Wear Resistant Abrasion Steel Plate
Leave a Message
Product Description

TISCO Nm400 Ar400 Ar500 Wear Plate/Wear Resistant Steel Plate

Thickness
6mm, 8mm, 12mm, 16mm, 20mm, 25mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm
Width
1500mm, 1800mm, 2000mm, 2200mm, 2500mm
Length
6000mm, 8000m, can cut to width and length
Packing Detail
according to customer's require or export's standard
Delivery Time
7 days for stock sizes, 20-25 days for new production sizes
Port
Tianjin China



Chemical Composition&Property
Grade
c
Si
Mn
P
S
Al
Cr+Ni+Mo
Nb+V+Ti
NM400
0.10-0.40
0.20-0.40
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 0.9
Trace Amount
NM450
0.10-0.40
0.20-0.40
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 1.2
NM500
0.10-0.40
0.20-0.45
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 1.5
NM550
0.10-0.50
0.20-0.45
1.00-1.50
Max 0.015
Max 0.003
Min 0.020
Max 2.0
NM600
0.10-0.50
0.20-0.45
1.00-1.50
Max 0.015
Max 0.003
Min 0.020
Max 2.5
XCHD400
0.10-0.30
0.20-0.40
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 0.1
XCHD450
0.10-0.40
0.20-0.40
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 0.9
XCHD500
0.10-0.40
0.20-0.45
1.00-2.00
Max 0.015
Max 0.003
Min 0.020
Max 1.5





Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent 0





Application
NM500 Steel Plate ar500 plate ar400 steel ar400 steel plate of NM500 steel sheet
1.common structural parts and parts for drawing in engineering machines
2. transportation machine construction machines, lifting machine,
3. agricultural machines, light and civil industrial, household appliance industries.
4. chemical equipments, drive casing pipe and light industrial civil industries.

Packaging & Shipping
Packaging
when each plate weight is under 1 ton, it will be in bundle with steel strips 2-4, when each plate weight is over 1ton, it will be piece by piece.
20 feet container contains dimension
Width under 2300mm, length under 6000mm
40 feet container contains dimension
Width under 2300mm, length under 12000mm
By bulk vessel
Freight charge is low by bulk cargo, and large heavy sizes can not be loaded into containers can shipping by bulk cargo



Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent 1


Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent 2Ar500 Abrasion Wear Resistant Steel Plate 200mm Nm400 NM400 NM450 NM500 NM550 NM600 wearEquivalent 3
Product Packaging
According to the properties and requirements of customers , Steel plate can hot-rolled, controlled rolling,
normalizing, annealing, tempering, normalizing add tempering, piece.modified such status delivery.

20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
20feet container load 25tons coils whose length is under 5.8m
40feet container load 25tons coils whose length is under 11.8m

Packing Details : Bundle with steel strip
Delivery Details : Use trays to facilitate loading and unloading
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required
FAQ

Q1: Are you a factory or trading company?
A1: We are a Chinese manufacture of steel pipes with both factories and trading companies.

Q2.How can you ensure the quality of your product?
A2.All products have to go through three checks in the whole manufacturing process,it includes production,cutting sheets and the packing.

Q3.What is your delivery time and the supply ability?
A3.The delivery time normally within 15~20working days,we can supply about 15,000tons every month.

Q4.What kind of equipment in your factory?
A4.Our factory have advanced five-eighth roller rolling,cold rolling production equipment on the roll,advanced processing and testing equipment,which makes our product better quality with efficiency.

Q5.About the complaint,quality problem,etc aftersales service,how do you handle it?
A5.We will have certain colleague to follow our order accordingly for each order with professional after-sales service. If any claim happen, we will take our responsibility and compensate as per contract. For better serve our client, we'll keep tracing feedback of our products from clients and that's what make us different from other suppliers. We're customer care enterprise.
