Place of Origin	CHINA
Brand Name	Duohe
Certification	ISO,SGS
Model Number	NM500
Minimum Order Quantity	3 tons
Price	negotiable
Packaging Details	Standard export packing (waterproof paper + steel rings), or as your requirement
Delivery Time	ship within 10 days after received the advance
Payment Terms	T/T, L/C, Western Union
Supply Ability	3000 tons per month

Name	Nm500 Abrasion Steel Plate	Standard	ASTM, AISI, GB, JIS, DIN, BS
Grade	NM450,NM500	Thickness	2-300mm
Width	1000-3000mm	Length	1000-12000mm
Technic	Hot Rolled	Finish	NO.1
Tolerance	±1	Application	Lifting Transportation Machinery
High Light	ar400 Abrasion Steel Plate , Nm400 steel sheet , Abrasion Resisitant Steel Plate

Wear Resistant Steel Plate Specification
Standard Grade	DIN: XAR300,XAR400, XAR450, XAR500, XAR600, DILLIDUR400V,DILLIDUR450V,DILLIDUR500V; X120Mn12; 1.3401; SSAB WELDOX700,WELDOX900,WELDOX960; NF: FORA400,FORA500,Creusabro4800,Creusabro8000; EN: QUARD400,QUARD450,QUARD500 ; RAEX320,RAEX400,RAEX450, RAEX500;DUrostat400,DUrostat450,DUrostat500; JIS: WEL-HARD400, WEL-HARD500; SUMIHARD-K340,SUMIHARD-K400,SUMIHARD-K500 GB: NM360,NM400,M450,NM500,NM550,NM600,NR360,NR400,B-HARD360, B-HARD400,B-HARD450,KN-55,KN-60,KN-63.
Thickness	2-300mm (2-100mm usually used)
Width	1000-3000mm (1000-2200mm usually used)
Length	1000-12000mm or as your request
Surface	Clean, finishing,blasting and painting according to customer requirement
Delivery States	Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,and other delivery states are available as required
Certificate	API,ISO,SGS,BV,CE etc
Quality	MTC will be provided with goods, third part inspection is acceptable, for example BV,SGS.
Package	Standard export seaworthy package,suit for all kinds of transport, or as required.
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
Container Size	40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
Trade term	Ex-Work,FOB,CNF,CFR,CIF,etc
Application	Widely used in a variety of architectural and engineering structures,such as 1.) metal constructions such as buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery; 4.) industrial furnace;boilers 5.) container frame, warehouse goods shelves, etc

Chemical Composition(Max)
Material	C	Si	Mn	P	S	Cr	Ni	Mo	Ti	Bt	Als	CEV
NM300	0.23	0.70	1.60	0.025	0.015	0.70	0.50	0.40	0.050	0.0005-0.0006	0.010	0.45
NM360	0.25	0.70	1.60	0.025	0.015	0.80	0.50	0.50	0.050	0.0005-0.0006	0.010	0.48
NM400	0.30	0.70	1.60	0.025	0.010	1.00	0.70	0.50	0.050	0.0005-0.0006	0.010	0.55
NM450	0.35	0.70	1.70	0.025	0.010	1.10	0.80	0.55	0.050	0.0005-0.0006	0.010	0.60
NM500	0.38	0.70	1.70	0.020	0.010	1.20	1.00	0.65	0.050	0.0005-0.0006	0.010	0.65
NM550	0.38	0.70	1.70	0.020	0.010	1.20	1.00	0.70	0.050	0.0005-0.0006	0.010	0.72
NM600	0.38	0.70	1.90	0.020	0.010	1.50	1.00	0.70	0.050	0.0005-0.0006	0.010	0.76

Packaging	when each plate weight is under 1 ton, it will be in bundle with steel strips 2-4, when each plate weight is over 1ton, it will be piece by piece.
20 feet container contains dimension	Width under 2300mm, length under 6000mm
40 feet container contains dimension	Width under 2300mm, length under 12000mm
By bulk vessel	Freight charge is low by bulk cargo, and large heavy sizes can not be loaded into containers can shipping by bulk cargo
